| Technical Specification: |
| Item | Specification | Remark | |||
| Capacity | Typical | 1250mAh | Measured at 0.2C discharge with 2.75V cut-off voltage, after standard charging | ||
| Minium | 1200mAh | ||||
| Normal Voltage | 3.7 V | Between 3.6V ~3.9V before shipping | |||
| Discharge cut-off Voltage | 3.0 V | ||||
| Max Charge Protection Voltage | 4.23 V | ||||
| Standard discharge current | 0.2C | ||||
| Max discharge current | 1.0C | ||||
| Standard charge current | 0.2C | Charge method: CC-CV (constant current and contant voltage ) | |||
| Max Charge current | 1.0C | ||||
| Diemnsion | 8*34*42mm | ||||
| Protection function | Over charge, Over discharge,Over load, Short Circuit | ||||
| High light | China manufacturer OEM 3.7V 7.4V 11.1 Volt li-ion polymer battery 1200mAh lipo battery 803442 Custom Lipo pouch battery 1500mAh Li-Polymer Lithium Polymer Lipo Battery 803442 manufacturer | ||||
| Lithium polymer battery features: |
● High Voltage: Norminal voltage up to 3.8V
● High Energy Density: Energy density up to 550 Wh/kg
● Stable Operating Voltage
More than 90% of the capacity could be output at a stable voltage
● Wide Operating Temperature Range: -20°C to +60°C
● Long cycle Life: More than 500 times
● Easily customized and flexibility in design
● Anti-overcharger,short-circuit production(with PCM)
● Light weight
● No memory effect
Visual Inspection:
They should not be any remarkable scratches, cracks,bolts, cauterization, deformations, swelling, leakage and so on the surface of the cell.
Applications: |
Digital products, smart mobile phone,smart electronic products; Miner's lamp,digital products. Portable electric ,Music box; Hair dryer,robot vacumm cleaner,wireless video doorbells; Modality equipment: Digital camera, DV, mobile DVD,
Smart wearable devices, Earphone, power bank,MPS, Tablet PC. laptop,GPS. Medical devices, electric children toys, electric shoes, electric blanket. Intelligent door lock, intelligent lighting, emergency light, industrial cameras.etc
| Production process: |
Warning:
Do not overcharge, force charge, short circuit, disassemble, deform, heat or place the battery near a direct flame.
Any of the above actions could cause it to ignite, explode or become damaged.
Keep this battery out of the reach of children.
When storing the battery or throwing it away, be sure to cover with tape.
Company Advantage | |||||||
|  |  | |||||
With three producing bases, sixteen advanced manufacturing lines, over 1650 staff, we can produce 20000,00 primary cells and 600,000 rechargeable battery packs per month. | Founded in 2004, Guangzhou Ser Battery Technology Co.,Ltd is CE. UL. SGS, IEC and ISO9001 certificated High-tech company. | Customers' interests always goes first,SER has a professional sales team, shipping team and after sales team to provide you with the best solutions and timely service. | |||||
 |  |
| |||||
Efficient and innovative R & D team helps the company lead in product design and superior performance | While keeping core competitivenes, SER also takes into account relevant social, economic and environmental goals, and always maintains sustained profitability and development capabilities. | For many years, the professional | |||||
Product Advantage | ||||
| 1. Full range of battery categories 17 years of development, SER have | 2. Safety The perfect protection IC has been used, | 3. Excellent and stable performance Strict control for cleanliness in dust-free | ||
4. OEM & ODM Ability Professional engineers have rich | 5. Technology Our dedicated and experienced engineers team always work together to our customers | 6. Delievry Fast delivery with standard package,will | ||
Hot tags:lipo battery 803442,li-ion polymer battery 803442,Lipo pouch battery,lithium polymer battery 1500mah,Lithium polymer battery with protection PCM,10000mah lipo battery,Lithium Polymer Battery with PH2.0mm JST Connector,3.7v Lithium Polymer Battery 10000mah,Lipo battery with flexible size,Customized,low temperature,manufacturers,suppliers,factory
