| Rechargeable and Unrechargeable ultra thin Battery |
Ultra thin Batteries | Excellent safety performance | ||||||||
● Once a safety hazard occurs, the liquid battery is easy to explode, while the polymer battery will only blow up at best. | |||||||||
| Thin thickness | |||||||||
Advantages
| ● The thickness can be less than 0.4mm, which meets the needs of current wearable devices. | ||||||||
| Light weight | |||||||||
| ● The weight of polymer battery is 40% lighter than steel shell lithium battery of the same capacity and 20% lighter than aluminum shell battery. | |||||||||
| Large capacity | |||||||||
| Small internal resistance | |||||||||
| The shape can be customized | |||||||||
Excellent discharge and charge characteristics | |||||||||
| TECHNICAL SPECIFICATIONS |
| LiMnO2 thin Soft Pouch Cell | |||||||
| Model | Normal Voltage | Normal Capacity | Max. Discharge current (mA) | Max. Pulse Capability (mA) | Dimension (mm) | Operating Temperature | Weight (g) |
| CP082922 | 3 | 60 | 10 | 20 | 0.8*29.5*22.5 | -20℃~ +71℃ | 1.5 |
| CP083645 | 3 | 250 | 50 | 100 | 0.8*36.5*45.5 | -20℃~ +71℃ | 3 |
| CP084248 | 3 | 320 | 50 | 100 | 0.8*45.5*48 | -20℃~ +71℃ | 3 |
| CP104248 | 3 | 400 | 100 | 200 | 1.0*45.5*48 | -20℃~ +71℃ | 3.7 |
| CP113130 | 3 | 165 | 10 | 50 | 1.15*31*30 | -20℃~ +71℃ | 1.5 |
| CP114951 | 3 | 380 | 100 | 200 | 1.1*49*51 | -20℃~ +71℃ | 3.7 |
| CP153350 | 3 | 400 | 100 | 200 | 1.55*33*50 | -20℃~ +71℃ | 4 |
| CP163350 | 3 | 450 | 100 | 200 | 1.6*33*50 | -20℃~ +71℃ | 4 |
| CP164848 | 3 | 520 | 100 | 200 | 1.6*48*48 | -20℃~ +71℃ | 4 |
| CP223638 | 3 | 500 | 100 | 200 | 22*36*38 | -20℃~ +71℃ | 4.5 |
| CP223830 | 3 | 380 | 100 | 300 | 2.3*38.5*30.5 | -20℃~ +71℃ | 3.6 |
| CP224248 | 3 | 850 | 200 | 400 | 2.2*42*48 | -20℃~ +71℃ | 7 |
| CP252525 | 3 | 240 | 50 | 100 | 2.6*25*25 | -20℃~ +71℃ | 1.5 |
| CP263638 | 3 | 700 | 100 | 200 | 2.6*36*38 | -20℃~ +71℃ | 6 |
| CP281314 | 3 | 50 | 10 | 20 | 2.85*13.5*14.5 | -20℃~ +71℃ | 1.5 |
| CP283636 | 3 | 700 | 150 | 300 | 2.8*36*36 | -20℃~ +71℃ | 6.5 |
| CP302650 | 3 | 1030 | 300 | 500 | 3.0*27*52 | -20℃~ +71℃ | 7 |
| CP302675 | 3 | 1450 | 350 | 700 | 3.2*26.5*75 | -20℃~ +71℃ | 11 |
| CP303450 | 3 | 1250 | 300 | 500 | 3.0*34*50 | -20℃~ +71℃ | 10 |
| CP372440 | 3 | 700 | 150 | 300 | 3.7*24*40 | -20℃~ +71℃ | 6.5 |
| CP383147F | 3 | 1350 | 300 | 500 | 4.3*31.5*47.5 | -40℃~ +60℃ | 11 |
| CP401830 | 3 | 400 | 100 | 200 | 4.1*18.5*30 | -20℃~ +71℃ | 3.7 |
| CP403346 | 3 | 1300 | 300 | 500 | 4.1*33*46 | -20℃~ +71℃ | 11 |
| CP403838 | 3 | 1500 | 600 | 900 | 4.1*38*38 | -20℃~ +71℃ | 11 |
| CP405050 | 3 | 2450 | 500 | 1000 | 4.0*50*50 | -20℃~ +71℃ | 21 |
| CP405555 | 3 | 3000 | 1000 | 3000 | 4.1*55.5*55.5 | -20℃~ +71℃ | 23 |
| CP407060 | 3 | 4300 | 1000 | 3000 | 4.1*70.5*60.5 | -20℃~ +71℃ | 32 |
| CP502025 | 3 | 420 | 50 | 150 | 5.0*20.5*25 | -20℃~ +71℃ | 4 |
| CP502425 | 3 | 530 | 200 | 300 | 5.1*24*25 | -20℃~ +71℃ | 4.5 |
| CP502440 | 3 | 1200 | 300 | 500 | 5.2*24*40 | -20℃~ +71℃ | 9 |
| CP502525 | 3 | 550 | 200 | 300 | 5.3*25*25 | -20℃~ +71℃ | 4.5 |
| CP502537 | 3 | 1200 | 300 | 500 | 5.1*25*37 | -20℃~ +71℃ | 9.5 |
| CP503333 | 3 | 1200 | 400 | 800 | 5.0*33*33 | -20℃~ +71℃ | 9 |
| CP552338 | 3 | 1000 | 300 | 500 | 5.5*23*38 | -20℃~ +71℃ | 7 |
| CP552623 | 3 | 630 | 200 | 300 | 5.5*27*23 | -20℃~ +71℃ | 6.5 |
| CP553145 | 3 | 1700 | 400 | 800 | 5.5*31*45 | -20℃~ +71℃ | 14.5 |
| CP603147 | 3 | 1900 | 400 | 800 | 6.0*31*47 | -20℃~ +71℃ | 19 |
| CP603448 | 3 | 2400 | 500 | 1000 | 6.0*34*48 | -20℃~ +71℃ | 21 |
| CP603450 | 3 | 2400 | 500 | 1000 | 6.0*34*50 | -20℃~ +71℃ | 21 |
| CP605050 | 3 | 3800 | 1000 | 2000 | 6.0*50*50 | -20℃~ +71℃ | 31 |
| CP6052164 | 3 | 15000 | 3000 | 5000 | 6.1*52.5*164.5 | -20℃~ +71℃ | 106 |
| CP651848 | 3 | 1200 | 400 | 800 | 6.5*17.5*48.5 | -20℃~ +71℃ | 8.5 |
| CP702236 | 3 | 1300 | 300 | 500 | 7.2*22*36 | -20℃~ +71℃ | 11 |
| CP702340 | 3 | 1500 | 500 | 900 | 3.0*27*75 | -20℃~ +71℃ | 11 |
| CP702440 | 3 | 1300 | 300 | 500 | 7.0*24*40 | -20℃~ +71℃ | 11 |
| CP7052164 | 3 | 17000 | 3000 | 5000 | 7.1*52.5*164.5 | -20℃~ +71℃ | 118 |
| CP754560 | 3 | 5000 | 1500 | 3000 | 7.5*44.5*60 | -20℃~ +71℃ | 36 |
| CP8043115 | 3 | 12000 | 3000 | 5000 | 8.0*43*115 | -20℃~ +71℃ | 83 |
| CP804660 | 3 | 5500 | 1500 | 3000 | 8.0*46.5*60.5 | -20℃~ +71℃ | 38 |
| CP8258160 | 3 | 22000 | 3000 | 5000 | 8.2*58.5*160.5 | -20℃~ +71℃ | 171 |
| CP8544115 | 3 | 13500 | 3000 | 5000 | 8.5*44.5*115.5 | -20℃~ +71℃ | 89 |
| CP903450 | 3 | 3500 | 1000 | 2000 | 9.0*34*50 | -20℃~ +71℃ | 29 |
As a professional manufacturer in the lithium battery industry, SER Battery has a variety of lithium polymer batteriess, including
1. low-temperature lipo battery,
2. high-rate Lipo battery and
3. normal soft-pack Lipo batteries.
APPLICATIONS |
Widely used for : Mobile phones /tablets/ laptops/ flashlights/ digital cameras / digital products/LED flashlights/ laser flashlights/outdoor lighting torches/engineering lighting/mining lamps /emergency lights/ electric toys/game consoles/ remote control planes/ Electric tools/cordless household appliances/electric bicycles/electric recreational vehicles/portable audio-visual digital/instrument balance vehicles, scooters, can also be used in automobiles, such as electric vehicles, starting power supplies, and energy storage in power systems superior.
It is the advantages of polymer lithium batteries in terms of safety performance, thickness, weight, capacity, internal resistance, shape, and discharge characteristics that allow lithium batteries to be widely used in drones, remote control models and other fields, and continue to expand the application field. Believe that polymer lithium batteries can be used more in all aspects of our lives in the future.
