Primary CC Batteries ER261020 Lithium Thionyl Chloride battery high energy for Oil prospecting equipment

Double C Batteries ER261020H CC SIZE Bobbin Type High Energy 3.6V Li-SOCL2 Battery for petroleum exploration equipment

Battery model: Double C battery,CC batteries,ER261020,ER261020H

Battery brand: SER

Battery performance index

1. Battery capacity: (23±2℃, 3.0mA/2.0V) 17Ah

2. Open circuit voltage: ≥3.64V

3. Load voltage: (8Ω, 20±5℃, time ≤10s) ≥3.20V

4. Continuous working currents: (20±5℃) 200mA

5. Large pulse working current: (20±5℃) 400mA

6. Operating temperature range: -55~+85℃

7. Battery storage life: 10 years

The main raw materials are all imported from abroad, and the sealed lithium battery produced is novel in technology and has the following notable features andeight advantages:

1. The energy density is as high as 680Wh/kg, which is the highest among various lithium batteries.

2. High open circuit voltage: up to 3.66 volts for single battery& high working voltage, working voltage varies with load, usually between 3.3~ 3.6V

3. Low self-discharge rate: the annual self-discharge rate is less than 2%; the storage life can be 10-15 years at room temperature.

4. Wide temperature range: -55℃~+85℃.

5. The working voltage is stable: more than 90% of the battery capacity is output on a high-voltage platform with almost constant voltage.

6. The Li-SOCL2 battery is well sealed, safe and free of leakage.

Energy-type Lithium Thionyl Chloride battery (including standard energy type and high-capacity type) generally works continuously for a long time with micro-current, and can provide medium-current pulses, and the working time can be as long as 8 years

Power-type Lithium Thionyl Chloride battery can be designed in different ways according to different uses. Generally, it mainly provides high current or high pulse current. At the same time, it can work continuously for a long time with low current, and the working time can reach 8 years;

High temperature Lithium Thionyl Chloride battery can be used in the temperature range of -40~125℃.

Various industries, laptop battery, portable DVD battery, IC card terminal battery, electronic door lock battery, electric toy battery, power tool battery, emergency lighting battery, alarm system battery, medical instrument battery, communication equipment battery, wireless microphone battery, instrument Instrument battery, PLC battery, CPU battery, CNC machine tool battery, water meter battery, electric meter battery, gas meter battery, oil exploration, medical equipment, anti-theft alarm and other civil fields, and are widely used in aerospace, underwater in the defense and military fields. Weapons, sonar, navigation and various radios, etc.Scope of application: It is suitable for various industrial and civil products. It has a wide range of uses and many varieties. The application fields cover communications, automobiles, petroleum, chemical industry, transportation, machinery, electronics, electrical, instruments, meters, security, medical care, home appliances, etc.
